McIntosh MCD301 SACD/CD Player


  • $4,250.00
    Unit price per
  • Save $1,750

Only 1 left!

Used in Excellent condition

The McIntosh MCD301 SACD/CD Player delivers breathtaking fidelity from both standard compact discs and SACD’s, “raising the bar” for both technical and sonic performance. Topping the list of features is a new, super-quiet SACD/CD drive mechanism that is completely enclosed in a die-cast, wrap-around chassis for resonance free operation. A die-cast aluminum disc tray lends a special touch of quality that you’ll appreciate every time you load a disc. A McIntosh premium linear power supply features an R-Core transformer and nested regulation to provide the voltage stability and freedom from noise that are necessary for the very best audio performance. 24-bit, 192kHz sampling PCM/DSD Dual-Mode Digital-toAnalog converters with balanced outputs feed a balanced analog output stage resulting in wide dynamic range and extremely low distortion. Rotary controls for track selection and volume lend an old-school analog feel to the operation of this digital product. Both fixed and variable outputs are supported and a low impedance headphone amplifier with ¼” jack is provided.

“precision drive extracts all the information from the disc” 2-Channel SACD/CD Player True Dual Mode DSD/PCM  Digital to Analog Converters Fixed Balance and Unbalanced  Audio Outputs Variable Balanced and Unbalanced Audio Outputs Headphone Output Optical and Coaxial Digital Outputs Two Times Read Speed on  CD/CD-R/CD-RW Twin Laser Optical Pickup  for SACD and CD Play Data Input IR Remote Control

DISC fORMATS SACD, CD, MP3, WMA NUMBER Of CHANNELS  2 ANALOG AUDIO OUTPUTS 2VRMS (Fixed Unbalanced) 4VRMS (Fixed Balanced) 6VRMS (Variable Unbalanced) 12VRMS (Variable Balanced) fREQUENCY RESPONSE SACD 4Hz-40KHz +0.5dB/-2dB CD 4Hz-20kHz +/-0.5dB S/N RATIO  110dB DYNAMIC RANGE  100dB TOTAL HARMONIC DISTORTION SACD 0.002% CD 0.003%

DIGITAL AUDIO OUTPUTS (CD Audio only) Format: SPDIF Optical: TOS Link, -15~-21dBm Coaxial: RCA Jack, 0.5V p-p @ 75ohms PICKUP Type: Twin Laser Wavelength: 650nm(SACD)/790nm(CD) Laser Power: CLASS 2a/CLASS 1 POWER REQUIREMENTS 100~240 VAC, 50-60Hz 35Watts OvERALL DIMENSIONS (H x W x D  INCLUDING CONNECTORS AND fEET) 6” (15.24cm) x 17-1/2” (44.5cm) x 15-7/8”(40.32cm) Note: When the Disc Tray is opened, the panel clearance required in front of mounting panel  is 6-3/4 inches (17.2cm). WEIGHT 28.2 pounds (12.79kg) net, 44.6 pounds  (20.23kg) in shipping carton

TWO CHANNEL SACD/ CD PLAYER The MCD301 is a two-channel SACD/CD player. SACD, hybrid SACD, CD, CD-R,  CD-RW discs can be played on the MCD301. LOW DISTORTION 24-BIT  DUAL-MODE D/A CONvERTER The MCD301 utilizes the 24-bit, 192-KHz Sampling PCM/DSD Dual-Mode D/A converter with a wide dynamic range and extremely low distortion. Music at all levels is reproduced with extreme precision and elegance. The sound is  truly exceptional. vARIABLE BALANCED AND  UNBALANCED AUDIO OUTPUTS Balanced for long cable runs in a noisy environment and unbalanced for short runs. Balanced offers optimum noise rejection. The maximum output level is 6Vrms which allows the direct drive of power amplifiers. OPTICAL AND COAxIAL  DIGITAL OUTPUTS Optical and coaxial digital outputs  are provided for use with an external  D/A Converter.

McIntosh Laboratory, Inc.
Binghamton, NY
web address:

in excellent condition.


DISCLAIMER: In the instance that you order a specific item that we do not in fact have in stock you will be contacted and a full refund will be issued.
